ENFORCER 7 GEARBOX KIT

Parts List

Instruction Manual

Chassis: High strength carbon fiber, molded lower front bumper for
added chassis protection
Drive: Rear wheel
Differential: New Custom Works proprietary gearbox with 2.60
reduction and optional gear differential
Spur Gear: Machined Truespeed 48P 96 tooth spur gear
Body: Clear untrimmed Knoxville sprint with 6×6 vortec wing
Shocks: MDX V2 Aluminum Shocks with screw on seals and Ti-Nitride Coated Shock Shafts
Shock Towers: Carbon fiber
Suspension: Front and rear aluminum mounts, patented adjustable rear
A-arms, easy access front droop screws for quick adjustment,
titanium turnbuckles
Roll Cage: Nylon, black in color
Caster: Adjustable front and rear, caster/toe-in refers to the
angle of the suspension when viewed from the side of the car in
relation to the chassis
Camber: Adjustable front and rear, camber refers to the angle of
the tops of the tires from vertical when viewed from front or
behind vehicle

Enforcer 7 Sprint Car Kit, Shocks, Roll Cage, Instructions, Gearbox
two Hook and Loop Battery Straps, clear Body and Vortec Wing

Radio: 2-channel with low profile steering servo
Motor: 540 size brushless
ESC: To match selected motor
Pinion Gear: 48 pitch to match spur gear and motor choice
Battery: 2C hard case LiPo
Battery Charger: Compatible with selected battery
Shock Oil: Silicone, 30 weight recommended
Tires and Wheels: 2″ diameter
